LG 32LB580U-ZB LED TV
LG 32LB580U-ZB is a 32-inch 81cm Smart High Definition LED TV with a maximum supported resolution of 1366×768. It is a direct LED TV with great features. Its sound output is a 20-watt (10W + 10W) RMS MS10 Dolby Digital Plus one-way speaker system. It features a Digital/Analog tuner supporting DVB-T, DVB-T2, DVB-C, DVB-S, DVB-S2 HD, and PAL, as well as SECAM and NTSC (3.58 and 4.43) in AV-only mode. Its refresh rate is 60Hz. Update frequency is 400 Hz.
The LG 32LB580U-ZB features multiple input-output interfaces for user connectivity, including triple HDMI connections, triple USB ports, SCART, CI+, Serial interface, and Additional connections such as digital audio output (SPDIF), audio L/R Input, and Headphones. It runs on the WebOS/NetCast 4.5 operating system.
General Specifications & Features:
Make: LG
Chassis: LE46B/LD46B
Model: 32LB580U-ZB
Display Size: 32″
HD Technology: FHD
Panel: LC320EUB
Display Format: 1080P Full High Definition
Screen Type: LED
Features Format: Smart
OS Version: WebOS
Processor: Dual-Core 0.9 GHz
Graphics Processor: 2-Core
RAM Capacity: 1.25 GB
Storage Memory: 4 GB ROM
Screen Resolution: 1920×1080
No of HDMI Ports: 3
No of USB Ports: 3
Wi-Fi Type: Wi-Fi
Built-In Wi-Fi: Yes
Ethernet (RJ45): Yes
Scart: Yes
Speaker Output: 20W (10W+10W)
Tuner: DVB-T, DVB-T2, DVB-C, DVB-S, DVB-S2
Firmware Type: EMMC Backup
NAND Memory: THGBM5G5A1JBAIR
Main Board: EAX65610905 (1.0)
Power Rating: 100V~240V 50/60 Hz
Power Consumption: 1.25 Amp
Note: The following firmware is an EMMC backup file. Kazmi Elecom Team is not responsible for any damage/loss caused by uploading/downloading the firmware. First, check and verify the main board, then install the software. If you are new to loading, installing, or updating software, firmware, or dump files, or are experiencing issues during firmware installation, please visit and read this information first.
LG 32LB580U-ZB Firmware for free download:
