MB-H352-PW-AS Smart Android Board
MB-H352-PW-AS is a high-speed smart network universal driver board with an FHD resolution of 1920×1080. It is dedicated to 32″ to 43″ screens. It has a powerful wifi system. Smart FHD TV features with Android Platform and great features to entertain, Full HD Wide Screen with better to work SMART feature. The MB_H352_PW-AS Smart Board has multiple ports: A/V, USB interface Ports, and many HDMI ports, Scart, and Headphones. MB_H352_PW-AS has a LAN/RJ45 Ethernet Connector interface port, also for the wired/cable internet network.
MB-H352-PW-AS is a Combo high-speed Network triple-play motherboard that has the ATV, Backlight Driver Board, and Power Supply Module built into it. The Video and Sound quality of the MB_H352_PW_AS Android board are very good, and the Response rate is very efficient. This China smart network board has an Android 12 version. The MB-H352-PW-AS board, bifurcated into two types according to its configuration, is given in the picture below.
Specifications & Features:
Brand/Mark: FHD Smart LED TV Main Board
Main Board Model: MB-H352-PW-AS
Main Chipset: Hi3751V352
Interface: Single/Dual LVDS
TV System: DVB-T/T2/S/S2/C
Operating System: Android 12.0
Ram: 1Gb
Rom: 8Gb eMMC
Backlight: 72 to 79 V 560 mA
Audio Output: 2x8w (8 Ω)
Resolution: up to 1920×1080 (32” to 43″)
Panel Power: 12V
Power Input: 100-240V AC
Service Menu Code: Source/Input 2008, Menu 1201
Firmware Name: HISI352S.bin
Firmware Type: USB Bootable
Product User: MOONX
Note: The following MB_H352-PW AS firmware is a USB bootable file. Kazmi Elecom Team is not responsible for any damage or loss resulting from uploading/downloading the firmware. First, check and verify the main board, then install the software. If you’re new and lack knowledge of loading/installing software/firmware or dump files, or are experiencing issues during firmware installation, please visit and read this first.
MB-H352-PW-AS Firmware files for free download:
