Vortex V50R0213VS LED TV
Vortex V50R0213VS is a 50-inch digital 4K UHD smart Android LED TV with a resolution of 3840×2160, supporting the latest operating system VIDAA. Vortex LED TV is a universal design with a backlight driver circuit and a power supply module. Vortex 4K Ultra High Definition LED TV has the best picture quality.
Vortex V50R0213VS has multiple connectivity ports like AV, three HDMI, USB, and Digital Tuner input (DVB T/T2, C, S/S2). Its special features are the E-Share, Bluetooth, Dolby, Mirroring option, WiFi support, and built-in Apps. Vortex LED TV firmware files are given below for the technician’s support.
General Specifications & Features :
Brand/Make: Vortex
Model: V50R0213VS
Mainboard: CV9602-B55
Supported Resolution: 3480×2160
Screen Format: 16:9
Chipset: MT9602
Platform: M7332
Operating System: VIDAA
CPU: Cortex A53*4 64-bit
GPU: G52(2EE)MC1
RAM: 1.5Gb
ROM: 4Gb
EMMC: THGBMTG5D1LBAIL
Sound Output: 8Wx2
Transmission: DVB-C/DVB-T/T2/S2
Video System: PAL/SECAM
Backlight Voltage: 117V
Backlight Current: 520mA
Backlight Power: NA
AC Input: 100-240V
Firmware Name: MstarUpgrade.bin
Firmware Type: EMMC Backup Dump
How to Write Vortex V50R0213VS EMMC Backup:
- Download the given Vortex-V50R0213VS EMMC backup shared in this post above
- Note the EMMC Pinouts in the given picture above
- JTAG the mainboard with the Programming Tool
- Write the EMMC data
- Done.
Note: The following Vortex-V50R0213VS firmware is a backup dump and USB upgrade file. Kazmi Elecom Team is not responsible for any type of damage/loss as a result of uploading/downloading the firmware. First, check and verify the main board, then install the software. If you are new and do not have enough knowledge of loading/installing software/firmware or dump files, or are facing any issues during firmware installation, then visit and read here first.
Vortex V50R0213VS Firmware files for free download:
