CV3553CH-C32 LED TV Board
CV3553CH-C32 is a simple ATV Driver Motherboard designed for LCD/LED TVs. This board is suitable for the Asia Pacific and Middle East markets. It is a Combo Board. The main power module, LED Backlight Inverter Circuit module, and ATV Card are built into this motherboard.
This board has all the features as per the latest requirements, such as HDMI input, USB interface, PC input, Component Input, TV, and Scart.CV3553CH-C32 firmware files are given below for the technician’s support.
General Specifications:
Brand/Mark: Universal Board
Model: CV3553CH_C32
Main Chip: MSD3553
Product: LED TV
LED Backlight: 550mA
Flash IC: 4/8 Mb
Sound Chip:
Tuner IC:
Backlight Voltage: 36-42V
Screen supported: 32-inch
Resolution: Up to 1920×1080
Panel Voltage: 5V, 12V
Power Input: 220V AC
Service Code:
Source/Input 2580 or Menu 1147
Note: The following firmware is a backup file. Kazmi Elecom Team is not responsible for any damage or loss caused by uploading or downloading the firmware. If you are facing any issues during firmware installation, visit and read here first.
CV3553CH-C32 firmware for free download:
