TP.SK529S.PB803 Smart Android Board
The Android network motorist smart LED television board TP.SK529S.PB803( N) has a 1920 x 1080 FHD resolution. The wifi system on TP_SK529S_PB803 is veritably important. Smart FHD television with the most recent Android Platform and fantastic features for Full HD Wide Screen entertainment with bettered Smart functionality In addition to the VGA interface for computers, the TP SK529S PB803 Smart Board has multiple A/ V harborage, USB interface anchorages, and three HDMI interface harborage. The wired internet network can use the LAN/ RJ45 Connector interface harborage on the TP- SK529S- PB803.
The Digital TV tuner( DTMB/ DVB- C/ ATSC/ ISDB- T) is bedded in the Combo Network Triple Play board TP.SK529S.PB803. This Android board has excellent plates and sound quality, and its response time is veritably quick. The China smart network board TP.SK529S.PB803 is ideal for LED panels ranging in size from 32″ to 43″. The technician can get support from the firmware train TP.SK529S.PB803( N). On the off chance that you’re defying any issues during firmware establishment, visit and read them first.
Technical and General Specifications:
Brand/Mark: Main Board (Android WIFI Network Drive Smart Board)
Main Board: TP.SK529S.PB803 (N)
Main Chipset: HV352
Operating System: Android 13
CPU: Multi Core Arm Cortex A53 64-bit
GPU: Mali 450
CPU Frequency: 1.2GHz
GPU Frequency: 432MHz
RAM: 1GB
ROM: 8 Gb
Resolution: up to 1920×1080
Backlight: 35V-52V 25W480mA
Screen Size supported: 32 to 43 Inch
Audio Output power: 2x8W
Mirror Mode: Yes
Logo Change: Yes
Bluetooth: Yes
Tuner: SI2159
Input Voltage: 200-240V AC
Firmware Name: allupgrade_an12_V3520N0E_8G_512X2MB_68.bin
Firmware Type: USB Updateable Firmware
Note The following given Software/firmware is USB upgradeable. Kazmi Elecom Team is not responsible for any type of damage/loss as a result of uploading/downloading the firmware.
How to Download Firmware Files:
Download all parts of the following given firmware/Software and then extract any one of them you will get the folder. Now copy the files to USB. For more Details about the download process watch the video Click Here
TP.SK529S.PB803 Software file for free download:
For video tutorials, visit “Kazmi Elecom” on my YouTube channel.
Tp.sk529s.pb803
Ooops.. Not work..
When extract rar file its seems to be fault..
Waiting for repaire!!
download both parts (500MB+357.9MB) then extract
I’ve don it.
Files are extracted so good as one file size about 1.7G
.. But i do put that PIN file in the usb flash memory on usb slot of tv.. Can’t do update..
Tv name TOP GENERAL
with one botton under the screen only.. No other bottons.. No menue no up. No down.. Nothing.. Just one button..
How to get tv entering updating mood!!
Trying many methods.. But all fails.. What is the correct way to do..
Please help.. I’ve done at all
it should boot automatically. otherwise open back cover and connect keypad or short the points
I’ve got it..all files are extracted as well…
But can’t to entering tv into updating mood..
Tv name top genera, with one botton under the screen only.. No other bottons..
Please help
How to entering tv into updating mood
.. Tv name is TOP GENERAL
With one botton under the screen only
