XIAOMI L32M5-5ARU Smart LED TV
XIAOMI L32M5-5ARU is an Intelligent, smart Android LED TV with High Definition 1366×768 resolution. XIAOMI-L32M5-5ARU is dedicated to 60 Hz screens. It has the latest Android version 11.0. It has the full features of input interface connectivity. It has multiple input connectivity ports like triple HDMI, Mini AV, Coaxial, headphones, Optical interface, USB ports, and an RJ45 Ethernet port for wired internet connectivity.
Its USB interface can be used for Firmware upgrades and multimedia playback. XIAOMI L32M5-5ARU is a digital and analog TV tuner built into the main board, which can receive analogtelevision (PAL/NTSC). It has a special connectivity feature of Bluetooth 5.1. This board has an inbuilt WiFi module and LAN interface. The MI L32M5-5ARU Firmware file is given below for the Technician’s support.
General Specifications:
Mark: XIAOMI MI
Model: L32M5-5ARU
Board Model: TPD.MS6683.PB791
Main Chipset: MSD6683BQHA-8-00H4
CPU: ARM Cortex-A53
GPU: Mali-T720 MP2
Android Version: 7.1
Panel: Panel: ST3151A05 // ST3151A07-2
Resolution: FHD
Audio Power: 2x8W (16 watts 8 ohm)
Backlight Current: NA
Backlight Power: NA
USB Ports: 2
HDMI Ports: 3
CI: Yes
Component: Yes
RJ45: Yes
Tuner: CDT-9NT372-63
Analog Tuner: PAL/SECAM/NTSC (AV) BG/DK/I/LL
Digital Tuner: DVB-T2/C/S2
Wifi: Yes
Mira-Cast: Yes
Memory (RAM): 1 GB DRAM
Storage (ROM): 8 GB EMMC Flash
EMMC: THGBMHG6C1LBAIL
Power Rating: 220V~240V 50Hz
Power Consumption: 45 watts
Firmware Type: USB Bootable
Firmware Name: MiTVUpgrade_6683.bin
Note: The following firmware is a USB bootable file. Kazmi Elecom Team is not responsible for any damage or loss resulting from uploading/downloading the firmware. First, check and verify the main board, then install the software. If you are new and do not have enough knowledge of loading/installing software/firmware or dump files, or are facing any issues during firmware installation, then visit and read here first.
XIAOMI L32M5-5ARU Firmware files for free download:
