5823-A8R30T-0P00 Smart Android Board
5823-A8R30T-0P00 is a non-combo HD & FHD DVB LED TV Android Board. It has a supported FHD resolution of 1920×1080 and is suitable for Refresh Rate 60 hertz D-LED backlight technology screen panels. It has PAL-M, PAL-N, and NTSC Color systems. It has multiple HDMI ports to connect a set-top box, Blu-Ray players, and gaming consoles, and also has more than one USB port to connect hard drives and other USB devices and play multimedia as well.
It has a Dolby Sound system that supports 20 Watts of sound output and HDR Display viewing. 5823.A8R30T.0P00 can support the Smart TV Features as Android. 5823-A8R30T-0P00 firmware files are given below for free of cost download to support technicians.
General Features & Specifications:
Brand: China
Board Model: 5823-A8R30T-0P00
Display Format: FHD 1080P
Screen Type: LED
Features Format: Smart
OS Version: Android 4.4.2
Chipset: Realtek RTD298x
Processor: Quad-Core
Graphics Processor: Dual-core
RAM Capacity: GB DDR3
Storage Memory: GB ROM
Screen Resolution: 1920×1080
No of HDMI Ports: 3
No of USB Ports: 2
Built-In Wi-Fi: Yes
Ethernet (RJ45): Yes
Speaker Output: 20W (10W*2)
Tuner: ATMB7811 DVB-T2/T/C
Power Requirement: AC 100 – 240 V, 50/60 Hz
Power Consumption: 85 W
Firmware Type: EMMC Backup Dump and USB Update
Firmware Name: Install.img
Product: IRIS
Note: The following firmware is a USB bootable and EMMC backup File. Kazmi Elecom Team is not responsible for any damage/loss caused by uploading/downloading the firmware. First, check and verify the main board, then install the software. If you are new and do not have enough knowledge of loading/installing software/firmware or dump files, or are facing any issues during firmware installation, then visit and read here first.
5823-A8R30T-0P00 Firmware for free download:
