SAMSUNG UE32F6100AK LED TV
SAMSUNG UE32F6100AK is a 32-inch (81.3 cm) Full HD Smart LED TV. Its supported screen resolution is 1080 Pixels, 1920×1080. Samsung makes the main board (BN41-01954A), which is a non-combo board. This LED TV has a powerful sound system with a 20-watt (10×2 watts) stereo speaker system. It has a Worldwide NTSC/PAL/SECAM Color System, DVB-T (DVB-C, DVB-T2, DVB-T)TV tuners.
The Samsung UE32F6100AK Smart LED TV has multiple user connectivity interfaces, such as dual HDMI input ports for connecting digital devices and a component input interface for analog device connectivity. It also has SPDIF for digital audio out and a single USB input port for multimedia playback and software upgrades. It also has a SCART interface, an Antenna RF, and a CI+ interface.
General Specifications & Features:
Make: SAMSUNG
Series: F6100
Model: UE32F6100AK
Display Size: 32″
Storage Memory: 132 MB
CPU: 4-Core
HD Technology: Full HD
Panel: HF320CSA-B1
T-CON: T320HVN03.1 32T36-C06 CTRL BD
No of HDMI Ports: 2
No of USB Ports: 1
Scart Interface: Yes
CI+ Interface: Yes
Digital signal format system: DVB-C, DVB-T2, DVB-T
Speaker Output RMS: 10W (5W*2)
NAND Memory: K9F1G08UOD (132MB)
Power Requirement: AC 100 – 240 V, 50/60 Hz
Power Consumption: 62 W, 0.5 W (Standby)
Software Type: NAND Backup Dump, SPI Flash Backup, EEPROM Backup
Software Name: NA
Main Board: BN41-01954A
Note: Samsung UE32F6100AK firmware is a backup dump file (NAND+SPI+EEPROM). Kazmi Elecom Team is not responsible for any damage/loss caused by uploading/downloading the firmware. First, check and verify the main board, then install the software. If you are new and do not have enough knowledge of loading/installing software/firmware or dump files, or are facing any issues during firmware installation, then visit and read here first.
SAMSUNG UE32F6100AK Firmware files for free download:
