T.R67.675 LED TV Board
T.R67.675 is a universal combo board with multi-memory and resolution software.
Basic Info:
Model No. T.R67.675 V1, V2, V3, V4
Main Chipset: UTS6710-X
Display Format: up to 1920×1080
Aspect Ratio: 4:3, 16:9 & 16:10
Tuner: 5160
Sound: CD1517CP
General Specifications:
TV System: PAL/SECAM/NTSC
Panel Interface: Single channel or Dual-channel LVDS
Key Button Functions: CH-/CH+/MENU/VOL-/VOL+Souce/Power
Multi-Language OSD: Yes
Input/Output Ports: HDMI, VGA, AV, USB, RF TV interface, and Earphone Out
Audio O/P Power: 2 x 3 Watt (8 ohms)
Panel Voltage: +5V/+12V DC
USB Port: Yes (Firmware Upgrade and Multimedia Playback Support)
USB File Format: Audio (Mp3, wma, m4a/aac), Video (avi, mp4, ts/trp, mkv/mov, mpg, dat, vob, rm/rmvb), Picture (Jpg, jpeg, bmp, png), Text (text)
IR Control: Yes (Controllable by Remote Control)
Electrical Parameters:
Working Input Voltage: AC 220
Maximum Current: 2000mA (Without Panel)
Standby Power: <0.2W (for the motherboard only)
Maximum Current for USB: 500mA
Factory Service Mode:
Input/Source 815
Input/Source 208
Multi-Logo Change:
Input/Source 336
Multi-Resolution Code:
- INPUT/SOURCE 03661 FOR 1920X1080
- INPUT/SOURCE 03662 FOR 1366X768
Note: The following given software/firmware is Backup Dump. Kazmi Elecom Team is not responsible for any type of damage/loss as a result of loading/installing the firmware. If you are new and do not have enough knowledge of loading or installing software/firmware or dump files then read here first.
How to Download:
Download the following given firmware/software and then extract you will get the folder. Now copy the files to USB. For more Details about the download process watch the video Click Here
T.R67.675 Firmware Free Download Here :
- T_R67_675_1366X768_SONY_MULTI-RESOLUTION
- T-R67-675 1366×768-USB
- T-R67-675 V4 1366×768-USB
- T-R67-675 V4 1920×1080-USB
For video tutorials, visit “Kazmi Elecom” my YouTube channel.
Hallo sir
Mene BPL 24INCH IED TV ME T.R67.675 universal combo board install kiya h. But usme screen ulta ho gya h aur colour bhi change h. Is board ka factory code bhi mene dala input336 is code me only logo change ho raha h but factory settings ka koi bhi option nahi a rha.
Please koi solution bataye
INPUT 208
Input 208 com nahi kar raha hai
SERVICE MENU INPUT 815 OK
Thanks
Sir T. R67. 675 univarsal bord lagaya but rrsulation problem h sahi nahi hota h code input 03661/ 03662bhi nahi lagta kare
input 815
T. R67. 675 board me lvds pin out details
all universal boards has the same pinouts
Sir New mother bord T. R67. 675 lagane pa maping problem kaise sahi hoga
Sir my my mobile number 8299621695
Sir T.R67.675 new mother board burning problem ho raha hi
videos me ja k follow karen
Video me Nehi ha
Sir
Tr67.675 ka 1980*1080 format sw milega
Sir
Tr 67.675 ka 1980*1080 format sw milega
multi resolution hy. code se ho jye ga
T.R67.675 card mein burning mod a gaya hai kya Karen power keyboard se theek nahin ho raha hai
software dobara load kar len
hello sir t.r67.675 is bord holl software chahiy…..
T. R. 67.675 ka software chahiy sir ji
Sir T.R 67.675 lcd new moderboard me burring (color change )problem hai to isaka password kya hai jabaki mene 03661 or 03662.or
Input 208
T .r67.675 burning mode hay
resolution mismatch ho sakti hy. correct software load karen
T.r67.675 combo ka software dawnload nhi ho Raha hai usko kase kare
Change swap ko unable karne se hui hai
software dobara hoga.
need the software
download
Change swap debane se pecture Nahi aaraha hai sir g kya kare
software dobara karen
T. R67. 675 software not available site
at the end of the post
unzip password
no password set
TR67.675 1366×768 degya plese
sir mujko t.r67.675 ka software chahiye…. mene y board new sumsung 24 inch me install kiya hai.. tv mene chala ke bhi dekha hai tv chala bhi hai but kuch dere bad logo tak aata hai restart ho jata hai… y problem hai…
hardware fault ho sakta hy
Tr 76.675 1366×768 ka software dena.
t.r67.675 iska software nahi hai
give me this file please please please
download
Model T.R67.675 matharboard ka 1920*1080 software link not working please upload the link
INPUT 03661 try karen
t-r67-675-software is not loading on my motherboard please help me
T.R67.675 combo bod ka software chahiye
Download kar len
Best
Cv358h-b42 remote & logo file need sir
NA
